Braided Cables

Multl Core Flexible Braided Castes


Core Colors : Up to 4 cores. Black with white numbering + yellow/green
Sheath Colors : Gray, black and white
Conductor : Annealed bare copper as per IS: 8130
Insulating PVC : Type A conforming to IS: 5831
Shielding : Aluminum mylar tape is wrapped on the laid up cores. identification nos. are marked on the cores.
Braiding : Annealed tinned copper wire braiding
PVC Sheath : Type ST—i conforming to IS: 5831
HR, FR and FRLS sheathing can be provided if required
Rated Voltage : 300/500 V
Test Voltage : AC 2000 V
Min. Bending Radius : 6 times the overall diameter of cable
Tensile Strength : 12.50 N per sq mm of PVC insulation and sheath
Max. Working Temperature : 70"C: also available for 85°C and l05"C
Max. Short Circuit Temperature : i60°C
Usage : Suitable for interconnection of electrical measuring devices to instrumental panel
or instrument. Also for measuring, monitoring and control in machine tool manufacturing in plant engineering. in places where interference field can distort a signal transmission or where interference pulses arising in the mains must be confined.
