Surface Wires LSZH

0.6/ I KV XLPE Insulated Low Voltage Power Cables

Application

Calter surface wires LSZH are used for fixed wiring and mains cable. used for mains connections under heavy current loads


Construction

Conductor: Electrolvic stranded plain copper class - 2 according to IEC 60228
Insulation : XLPE
Sheath : special polyolefin thermoplastic-cross linked, LSZH


Techical Data

Halogen free : IEC 60754-1
Rated Voltage Uo/U (Um) : 0.6 / 1 kV
Operating Temerature range : -40 C to +90 C
Max. Conductor temperature in service : 120 C
Short-circuit max. conductor temperature : 250 C
Gases Corrosivity : IEC 60754-2
Smoke density : IEC 61034-2
Weather resistance : Excellent
UV Resistant : Yes
Flame retardent : IEC 60332 - 1
