H07RN-FCable

Application

CALTER RUBBER Cables is extreme weather, oil & grease, water resident cable. Applicable for industrial and outdoor hanging and & extreme flexibility is required. The Cable is particularly suitable for heavy industry, oil & chemical indusries as the rubber is oil & grease resistant, fire resistant, Halogen free also used in turbines, marine & submersible pumps


Construction

conductor : Electrolytic Flexible plain copper class - 5 according to IEC 60228
Insulation : special formulated thermoplastic rubber
Sheath : Special formulated thermoplastic rubber compound


Colour Coding

2 core - brown, blue
3 core - brown, blue, green/yellow
4 core - brown, blue, black, green/yellow
5 core - brown, blue, black, Black,
green/ yellow


Techical Data

Halogen free : IEC 60754-1
Rated Voltage Uo/U (Um) : 450/750 V
Operating Temprature range : -40 C to +90 C
Max. Conductor temperature in service : 90 C
short-circuit max. conductor temperature : 200 C
gases corrosivity : IEC 60754-2
weather resistance : Excellent
UV Resistant : Yes
Flame Resistant : IEC60332-1
Mechanical Abrasion, tear, notch, pressure resistant : Excellent
oil & chemical resistant : Excellent
