Brass Extruded Cable Glands: Type CW

Application
In outdoor areas with armoured or braided cable , including lead sheathed.
Function:
All glands offer clamping of the armour or braid and a weather seal to the outer sheath of the cable.

Standard: BS 6121: Pt1
Mechanical : Provides retention of armour or braid impact resistant
Size: CW 20S -75L
Material: BS 2874 (Cz121) Brass
Finish: Matt/Nickel
Gasket : Seal rated to IP66
Shrouds : Pvc/Lsf
Kits: CW Gland, Shrouds, Locknut and Earth Tag
Gland rated to IP66 with use of suitable sealing washer or thread sealant at gland interface.
